RX2

Emlid Reach RX2 brings centimetre-level RTK positioning to surveying, mapping, and scanning projects, enabling field professionals to collect accurate data with a compact, rugged receiver.

• Capture centimetre-level positions: Multi-constellation GNSS support provides reliable RTK positioning for demanding field applications.
• Measure without levelling the pole: IMU tilt compensation supports efficient measurements near walls, slopes, and other tight spaces.
• Connect to RTK corrections: Work with CORS or NTRIP services using RTCM3 for straightforward field setup.
• Work all day with less equipment: A 280 g pocket-sized design, IP68 protection, and up to 16 hours of battery life support mobile fieldwork.

Overview and Who It's For

Emlid Reach RX2 is a pocket-sized RTK GNSS receiver designed for professional surveying, mapping, and geospatial data collection. It combines centimetre-level positioning, IMU tilt compensation, multi-constellation GNSS support, and integration with Emlid Flow and compatible field applications.

• Surveying professionals: Capture precise RTK positions with tilt compensation for efficient field measurements.
• Mapping and GIS teams: Integrate with ArcGIS Field Maps, Survey123, QField, PIX4Dcatch, and other compatible workflows.
• Utilities and construction teams: Collect accurate positioning data around infrastructure, walls, slopes, and tight spaces.
• Scanning professionals: Add centimetre-level positioning to terrestrial scanning projects in a compact field-ready receiver.

Key Specs

FAQs

What positioning accuracy does Emlid Reach RX2 provide?
RTK positioning is specified at 7 mm + 1 ppm horizontally and 14 mm + 1 ppm vertically.

Does Reach RX2 support tilt compensation?
Yes. IMU tilt compensation allows measurements without levelling the pole, including around walls, slopes, and tight spaces.

Which GNSS constellations does Reach RX2 support?
Reach RX2 supports GPS, GLONASS, Galileo, BeiDou, QZSS, and NavIC.

Which field applications are compatible with Reach RX2?
Reach RX2 is compatible with ArcGIS Field Maps, Survey123, QField, PIX4Dcatch, and other supported workflows.

How long does the Reach RX2 battery last?
Reach RX2 provides up to 16 hours of battery life and supports USB-C fast charging in under 3 hours.
