DJI SDR Transmission 2

On professional film sets, live events, and location productions, a wireless video link that drops signal mid-take or loses connection in a crowded RF environment is not just an inconvenience - it stops the entire crew. The DJI SDR Transmission 2 is a compact single-transceiver wireless video system built on Software-Defined Radio technology, delivering 1080p/60fps video at 20 Mbps and 35 ms latency across up to 3 km, with automatic frequency hopping across 2.4 GHz, 5.8 GHz, and DFS bands to maintain a clean signal in the most challenging RF environments.

• 3 km transmission range with automatic frequency hopping: The SDR Transmission 2 reaches up to 3 km and automatically switches between 2.4 GHz, 5.8 GHz, and DFS frequency bands when interference is detected, maintaining a stable signal across crowded sets, urban environments, and complex architectural spaces without manual channel management.
• 1080p/60fps at 20 Mbps and 35 ms latency: Delivers full HD 1080p video at 60 frames per second with a transmission bitrate of up to 20 Mbps and minimal 35 ms latency, providing the image quality and responsiveness that directors, focus pullers, and script supervisors need for reliable on-set monitoring.
• SDI, HDMI, and USB-C outputs for flexible monitoring: Connect to professional monitors via SDI or HDMI, or connect the receiver directly to a smartphone or tablet via USB-C for portable monitoring without a dedicated display. Simultaneously outputs three SDR signals and two Wi-Fi signals for multi-station monitoring coverage.
• Broadcast mode for unlimited receivers: In Broadcast mode, a single transmitter connects to an unlimited number of receivers, enabling simultaneous monitoring feeds for the director, 1st AC, script supervisor, and client village from one transmitter without signal degradation.
• DJI RS series gimbal control and remote camera operation: Paired with compatible DJI RS series gimbals (RS 4 Pro, RS 4, RS 3 Pro), the SDR Transmission 2 enables remote gimbal control and remote camera parameter adjustment including aperture, shutter, and ISO, reducing the need for on-set cable management.
• NP-F battery, USB-C PD, and gimbal-direct power options: Powers via industry-standard NP-F batteries, USB-C PD charging, or directly from a connected DJI RS series gimbal, supporting flexible power setups across different production configurations.

Overview and Who It's For

The DJI SDR Transmission 2 is designed for professional film crews, broadcast production teams, and live event operators who need reliable wireless video transmission with monitor-grade image quality, multi-station distribution, and low latency. This is the single-transceiver configuration providing one transmitter for setups where additional receivers are purchased separately. The Combo 2 includes two transceivers for a complete TX and RX pair out of the box. Compatible with DJI Ronin app for monitoring tools including LUT, Peaking, Waveform, False Color, and voice call functionality.

Key Specs

What's Included

• DJI SDR Transmission 2 Transceiver x1
• DJI SDR Transmission 2 Camera Cold Shoe Adapter x1
• DJI SDR Transmission 2 NP-F Battery Adapter x1
• Firmware Update Cable (USB-C to USB-C, 50 cm) x1

Warranty and Returns

This product includes a standard DJI manufacturer warranty. Candrone's standard return and exchange policy applies.

View Candrone's Warranty and Returns Policy

For support or to speak with a solutions specialist, contact our team at 1-888-461-5742 or visit our Contact page.
